| Model | Uho‑P2C‑M4F4 |
| Camera |
| Max Resolution | 4 MP |
| Sensor | 1/2.9" CMOS |
| Min. Illumination | Colour: 0.0003Lux (F1.0, AGC ON) |
| Shutter | Auto/Manual, 1 to 1/100000 s |
| S/N | > 52 dB |
| WDR | DWDR |
| Lens |
| Digital Zoom | 4X |
| Focal Length | 4.0 mm |
| Iris Type | Fixed |
| Iris | F1.0 |
| Field of View (H) | 85.4° |
| Field of View (V) | 47.5° |
| Field of View (D) | 98.5° |
| Lens Type | Fixed |
| DORI |
| DORI Distance (Lens) | 4.0mm |
| DORI Distance (Detect) | 64.3 (210.9 ft) |
| DORI Distance (Observe) | 25.7 (84.4 ft) |
| DORI Distance (Recognize) | 12.9 (42.2 ft) |
| DORI Distance (Identify) | 6.4 (21.1 ft) |
| Illuminator |
| Supplemental Light | Warm light |
| Illumination Distance (Warm Light) | 30 m (98.4 ft) |
| Video |
| Video Compression | Ultra 265, H.265, H.264 |
| Frame Rate | Main Stream: 4MP (2560*1440), Max 25fps; 3MP (2304*1296), Max 30fps; 2MP (1920*1080), Max 30fps; 720P (1280*720), Max 30fps;
Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360, Max 30fps; 2CIF (704*288), Max 30fps; CIF (352*288), Max 30fps; |
| Video Bit Rate | 128 Kbps to 6144 Kbps |
| U‑code | Support |
| OSD | Up to 4 OSDs |
| Privacy Mask | Support (only NVR) |
| ROI | Support |
| Video Stream | Dual Streams |
| Image |
| White Balance | Auto, Outdoor, Fine Tune, Sodium Lamp, Locked, Auto2 |
| Digital Noise Reduction | 2D/3D DNR |
| Smart Illumination | Support |
| Flip | Normal, Flip Vertical, Flip Horizontal, 180° |
| Dewarping | N/A |
| HLC | N/A |
| BLC | N/A |
| Defog | Digital Defog |
| Events |
| Basic Detection | Human Body Detection, Motion Detection, Audio Detection |
| General Function | IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication, HTTP Authentication |
| Intelligent |
| Auto Tracking | Support |
| Audio |
| Audio Compression | G.711U, G.711A |
| Audio Bitrate | 64 Kbps |
| Two‑way Audio | Support |
| Suppression | Support |
| Sampling Rate | 8 kHz |
| Storage |
| Edge Storage | Micro SD, up to 512 GB |
| Network Storage | ANR |
| Network |
| Wi‑Fi | 2.4G Wi‑Fi (IEEE802.11b/g/n/ax), built‑in antenna |
| Protocols | IPv4, TCP, UDP, DHCP, RTSP, DNS, DDNS, NTP, HTTP |
| Compatible Integration |
API |
| Client | Uniarch Client, Uniarch app |
| Web Browser | Plug‑in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+ |
| Wi‑Fi |
| Wireless Standards | IEEE802.11b/g/n/ax |
| Frequency Range | 2.4 GHz to 2.4835 GHz |
| Channel Bandwidth | 20/40 MHz Support |
| Modulation Mode | 802.11b: CCK
802.11g/n: OFDM
802.11ax: OFDMA |
| Wi‑Fi Security | 64/128‑bit WEP, WPA‑PSK/WPA2‑PSK |
| Transmit Power | 802.11b: 17±1.5 dBm@11 Mbps802.11g: 16±1.5 dBm@54 Mbps802.11n: 16±1.5 dBm@MCS7802.11ax: 16±1.5 dBm@MCS9 |
| Receive Sensitivity | 802.11b: ‑76 dBm@11 Mbps (Typical)802.11g: ‑65 dBm@54Mbps (Typical)802.11n: ‑61 dBm@MCS7, HT40 (Typical)802.11ax: ‑54 dBm@MCS9, HE40 (Typical) |
| Transmission Rate | 802.11b: 11 Mbps802.11g: 54 Mbps802.11n: up to 150 Mbps802.11ax: up to 270 Mbps |
| PTZ |
| Pan Range | 0° ~ 345° |
| Pan Speed | 1°/s ~ 40°/s
Preset speed: 40°/s |
| Tilt Range | 0° ~ 90° |
| Tilt Speed | 1°/s ~ 30°/s
Preset speed: 30°/s |
| Number of Presets | 20 |
| Interface |
| Audio I/O | N/A |
| Alarm I/O | N/A |
| Built‑in Mic | Support |
| Built‑in Speaker | Support |
| WIFI | Support |
| Network | 1 × RJ45 10 M/100 M Base‑TX Ethernet |
| Certification |
| EMC | CE‑EMC (EN 55032, EN 61000‑3‑3, EN IEC 61000‑3‑2, EN 50130)
FCC (FCC 47 CFR part15 B) |
| RF | FCC ID (FCC CFR 47 part15 C)
CE RED (EN 301 489‑1, EN 301 489‑17, EN 300 328, EN 62311) |
| Safety | CE LVD (EN 62368‑1) |
| Environment | CE‑RoHS (2011/65/EU; (EU) 2015/863) ; WEEE (2012/19/EU) ; |
| Protection | IP66 (IEC 60529) |
| General |
| Power | DC 12V±25% |
| Power Consumption | Max 6.5W |
| Power Interface | Ø5.5 mm coaxial power plug |
| Dimensions | Φ109mm*141mm*151mm (Φ4.3”x 5.6”x 6.0”) |
| Weight | 0.39kg (0.85lb) |
| Working Environment | ‑30 ℃ to 60 ℃ (‑22 ℉ to 140 ℉), Humidity: ≤ 95% RH (non‑condensing) |
| Storage Environment | ‑30 ℃ to 60 ℃ (‑22 ℉ to 140 ℉), Humidity: ≤ 95% RH (non‑condensing) |
| Surge Protection | 4 KV |
| Reset Button | Support |
| LED Indicator | 1, red/blue |
